- Painted grey finish
- inside button and cylinder models.
- Available in Right.
- Fixed outside 50 mm. cylinder length, adjustable length from 35 till 90 mm.
- Backsets 50-60-70-80 mm. for self locking latchbolt and deadbolt models
- single solenoid unit
ADDITIONAL PRODUCT INFORMATION
- Stop device: by pushing button and at the same time turning the key clockwise it is possible to hold latchbolt in open position. By turning the key clockwise only the pushbutton is deactivated holding latchbolt in closed position.
- Keep with roller reducing frictions during opening and closing operations.
- Single solenoid unit, both working with voltage 12 V ac 15W.
- Special wire coupling with terminals for quick clamping.
- Ergonomic button and pulling handle.
- Suitable for replacing many models of electric locks.
- Operation: outside by key, inside by push button or key.
- Outside cylinders with 5 pin tumbler key mechanism (2 picking resistant) with thousands of different combinations preset and bit by computer system equipments. 50.000 cycle durability.
- Paracentric keyway.
- Self locking latchbolt.
- Single and double throw heavy duty deadbolt.
- Protected solenoids preventing anyone reaching them from outside.
- CE product certified.
- Steel case and keep.
- Nickel plated brass or nickel plated zinc alloy latchbolt and deadbolt.
- ABS or steel button and handle.
- Extruded solid brass cylinder body and plug.
- Inox steel cylinder springs.
- Brass strip for keys.
- Solenoids supplied by most reliable manufacturer.
- Case and staple electrostatically coated by epoxidic powder over zinc plated material
- suitable for outdoor fitting.
- Zinc plated case and keep suitable for outdoor fitting.
- Zinc plated keep supporting plate.
- Nickel plated brass keys.
Made in Italy
